I went through this against main and the problem is real. liveAssistantContent() calls parseAssistantContent, which re-slices the whole accumulated reply on every chunk (studio/frontend/src/features/chat/utils/parse-assistant-content.ts:107-137), so publishing per chunk is quadratic in the reply length. The render-layer coalescer you added in #8750 (markdown-text.tsx:401) sits downstream of that and cannot remove it, so this is not redundant with that work. The measurements look consistent with what the code does.

Three things I think need addressing before this merges.

1. Stop now truncates the saved reply

This is the one I would prioritise. The PR describes it as a limitation, but it costs more than the description implies.

chat-adapter.ts:4518-4520 states the invariant this gate breaks:

// Every streamed yield carries the repaired text, not just the terminal ones:
// assistant-ui drops whatever is yielded after an abort, so on Stop the last
// STREAMED yield is what gets saved.

Same thing again at thread.tsx:5597 ("the adapter yields nothing after an abort"), and the abort branch confirms it: chat-adapter.ts:6337 guards the partial yield with if (!abortSignal.aborted), so a real Stop publishes nothing. Before this PR every chunk yielded, so Stop kept everything received. Now whatever arrived since the last open frame is gone.

Two details that make it worse than "one frame":

The window is up to 500 ms, not ~16 ms. The gate reopens on requestAnimationFrame or the UNPAINTED_REOPEN_MS timer. When the main thread is starved, rAF is late and the timer is what reopens, so the closed window stretches toward 500 ms. That is exactly the condition this PR targets, so the loss is largest precisely when the gate is doing the most work. At the 440 tok/s you measured that is roughly a paragraph.

The lost text is unrecoverable, not just unpainted. Autosave exports published runtime state at thread.runEnd (runtime-provider.tsx:1849, :1909), so the truncated message is what gets written to the backend and survives a reload. Continue then prefills from message.content (thread.tsx:5571, passed at :5635), so a resumed turn restarts from the truncated point, potentially mid-word.

Worth noting that both coalescers already in this codebase are trailing-edge and do not have this problem:

• markdown-text.tsx:433-436 schedules setDisplayed(pendingRef.current) on the frame, so the withheld tail always lands.
• research-run-store.ts:762, :921-925 arms a flush timer and flushes on any non-coalescable event.

createFrameGate returns a boolean, so it structurally cannot flush anything. Two ways out:

• Give the gate ownership of the publish so the reopen callback can emit the pending text (trailing edge, matching useCoalescedStreamingText). Bigger change, since you cannot yield from a timer callback inside an async generator, so it likely means moving the pacing to createPersistedRunAdapter (runtime-provider.tsx:1114-1115) where the yields pass through.
• Or keep the leading-edge gate and add a length escape at chat-adapter.ts:6104, e.g. track lastPublishedLength and publish anyway once cumulativeText.length - lastPublishedLength exceeds some N. That bounds the Stop loss in characters instead of in wall-clock time, and keeps almost all of the coalescing win.

2. The integration test passes with the gate removed

chat-stream-publish-gate.test.ts:145-171 reads chat-adapter.ts as text and asserts on indexOf positions. I copied the two source files and the test into a scratch tree and mutated the copy. Both of these leave it green at 8/8:

Mutation A, comment out the entire gate. The PR is effectively reverted, and the test does not notice, because indexOf matches the text inside the comment:

              // if (!canPublish()) {
              //   continue;
              // }

ℹ tests 8
ℹ pass 8
ℹ fail 0

Mutation B, move createFrameGate() inside the loop. A fresh gate per chunk means painted is always true, so there is zero coalescing:

            for await (const chunk of stream) {
              const canPublish = createFrameGate();

ℹ tests 8
ℹ pass 8
ℹ fail 0

Mutation B is the one the test believes it covers: its own assertion message says "the run creates one gate per request", but loopStart points at line 5329, the construction site, not at the for await, so nothing anchors the gate to the loop.

Source-grepping is fine and well established here (68 of 294 files in studio/frontend/tests/ use readFileSync), so this is about tightening this instance rather than changing the approach. chat-autoscroll-frame-budget.test.ts:26-30 already shows the shape: slice the region first, then assert inside the slice. Slicing the for await (const chunk of stream) { body and stripping comments kills both mutations, and asserting the construction is outside that slice kills B specifically.

For what it is worth, the other 7 unit tests are good. The quiet-tail case at :47-74 and the late-frame-after-timer case at :133-143 in particular are exactly the right things to pin.

3. Only one of four publish sites in the loop is gated

All four of these yield liveAssistantContent(), so they all pay the same full rebuild:

"Tool-call updates are unchanged" is accurate, but it means the fix does not reach a tool-calling turn. tool_args is emitted per argument delta while the model writes the call, and the comment at :5467-5470 says why ("the card shows the code live"), so a long code_interpreter payload streams into the same hot path at the same rate as on main. Given your numbers for main under throttling, that turn stays in the old regime.

Gating in createPersistedRunAdapter would cover all four sites in one place, and it is also the natural home for the trailing-edge flush from point 1.

Smaller things

• stream-pacing.ts:23-24 schedules both a frame and a timer and cancels neither. The woken latch makes this correct and pending depth is bounded at roughly 30, so it is not a leak, but the same generator clears warmupTimer in its finally (chat-adapter.ts:6399) and useCoalescedStreamingText calls cancelAnimationFrame (markdown-text.tsx:411-416). Cancelling the loser once one fires would match what is around it.
• The schedule parameter has no production caller. chat-adapter.ts:5329 is the only call site and it uses the default. Three of the eight tests already stub globalThis.requestAnimationFrame and globalThis.setTimeout directly (chat-stream-publish-gate.test.ts:87-106) and exercise the default path, so the injection point is not buying coverage the tests cannot get otherwise. Dropping it takes the factory down to about ten lines.
• painted reads as a stronger claim than the code makes. rAF callbacks run before paint, and the publish they enable happens on a later chunk and commits some frames after that. "The gate is open" is what it tracks.
• One chunk-level value is read after the gate: structuredReasoningContinues (chat-adapter.ts:6133, destructured at :5879-5882), so a skipped chunk's value is dropped. It only gates finishGroup(), and measure() recomputes from startedAt[index] with later finishes overwriting earlier ones, so it does not change the result today. Might be worth a line at :6133 so the next person does not have to re-derive that.

Things I checked that are fine

• Everything the continue skips other than the yield is safe. TTFT (:6073-6078), totalChunks (:5850), the finish_reason latch (:5853-5857), chunk.usage (:5841-5846), the whole tool-call accumulator, and all five cumulativeText writers are pre-gate.
• The reasoning-duration tracker calls at :6110-6137 are skipped, but the drift is bounded by the gate interval and measure() rounds to whole seconds (reasoning-duration.ts:128). The back-fill-with-zero path at :155-160 can only mis-attribute a group that lived under 500 ms, which rounds to zero anyway. Not an issue.
• Normal completion (:6265) and non-abort failure (:6350) both publish the full cumulativeText, so the PR's claim there holds.
• requestAnimationFrame availability is not a concern. No SSR or worker path reaches this module, tsconfig.app.json:6 includes DOM, and bare unqualified rAF is already used elsewhere (adapters/dictation-level.ts:82).
• npm test on the new file: 8 passed. tsc -p tsconfig.test.json clean.

Thanks for the detailed review. Points 1 and 2 are real and I took both; point 3 in part. It is all in e555607.

1. Stop truncating the saved reply

Confirmed, and the mechanism is stricter than the comments you quote imply. I checked it at the library level rather than reading it off them. @assistant-ui/core's local runtime consumes the run like this (dist/runtimes/local/local-thread-runtime-core.js:324):

for await (const r of promiseOrGenerator) {
    if (abortSignal.aborted) {
        updateMessage({ status: { type: "incomplete", reason: "cancelled" } });
        break;
    }
    updateMessage(r);
}

The consumer drops the value. So the if (!abortSignal.aborted) guard at chat-adapter.ts:6337 is not what makes post-abort text unrecoverable: nothing yielded after a Stop can reach the message, whoever yields it.

That rules out both of the ways out you sketched, which is why I did not take the restructure.

• Moving the pacing into createPersistedRunAdapter does not change it. An async generator cannot yield from a timer callback, and even if it could, the loop above discards the value.
• A trailing edge fixes the quiet-tail case but not this one. Under a fast stream the next chunk arrives right after the gate reopens, so leading and trailing edge leave the same text unpublished: one gate interval of stream. That interval is exactly what stretches toward 500 ms when rAF is starved.

So the loss can be bounded, not removed. I bounded it in characters rather than in time, because characters are what is at risk and the bound then does not move with the stream rate: MAX_HELD_CHARS = 256, published regardless once that much has arrived since the last publish. A stop now discards under 256 characters in every case, including a stream that stalls without ending, instead of whatever a 500 ms unpainted interval produced. At this model's rate 256 characters is roughly 150 ms, so the cap only binds once frames are already several times slower than 60 Hz, which is the regime where the loss was largest.

Measured with Chromium against a local Studio running unsloth/Qwen3.5-0.8B-MTP-GGUF Q4_K_M at 12x CPU throttling, on three builds of the frontend: the merge-base, the PR head, and the PR head plus this commit. The received text is teed off the response body inside the page, so what arrived is known independently; the saved text is read back from the message after the run ends, both whitespace-normalised. A Stop click is scheduled from the page 900 ms into the reply. Three runs each, in run order:

Two things to read carefully there. On the merge-base the click never landed during the reply at all: the timer carrying it is starved with everything else, so it fired only after the stream had already closed, which is why that row's last column is just the whitespace-normalisation floor and not a Stop measurement. And on the PR head the loss is real and much larger than one frame, 589 characters in the worst run, which is your point.

Two runs per build were left to finish normally instead of being stopped. Those dropped 0 to 7 characters out of 5.9k to 10.5k, so the unconditional final update still carries everything on a normal end.

2. The integration test

Reproduced both mutations in a scratch tree before touching anything: 8/8 green with the gate commented out, 8/8 green with createFrameGate() moved inside the loop.

Rewritten the way you suggest, in the chat-autoscroll-frame-budget.test.ts shape: slice the for await (const chunk of stream) body, strip comments (keeping a // that sits inside a string literal), assert inside the slice, and assert the construction sits outside it. Where the file stands against mutation now:

The schedule parameter is gone. Every gate test now stubs the real globals, so the default path is the only one under test.

3. Publish sites

I took tool_args. It is the one in your code_interpreter example, and it is purely a preview: parseLiveToolArgs feeds a partial parse into the part and tool_start overwrites args and argsText with the authoritative one, so a skipped publish there cannot lose anything.

I left the other two ungated on purpose.

• tool_start and tool_end (:5824) are two events per call, so gating buys no coalescing, and they carry the card's running and done state.
• delta.tool_calls (:6057) mutates the tool-call part list rather than previewing it. A skipped publish there can leave an aborted turn without a call that the merge-base would have kept, which is point 1 again in a different shape.

So the rule is to gate the preview rebuilds and never the publishes that carry state, with the reason at the call site.

Smaller things

All four taken.

• Whichever of the frame and the timer fires now cancels the other, and the latch is per cycle so a callback left over from a spent cycle cannot reopen the next one. Both have a test.
• painted is now open, which is what it tracks.
• One line at the structuredReasoningContinues read. Your reading of it is right: every finish re-measures from startedAt[index], so the final one lands the correct duration either way.

npm test is 2402 passing, typecheck and build clean.

One consequence for the description: its Limitation paragraph is out of date, since what a stop can omit is now bounded at under 256 characters rather than a whole gate interval.

Codex Review: Didn't find any major issues. Swish!

Reviewed commit: 60e54dde32

I think we should simplify this before adding more reasoning-specific reconciliation.

The current placement makes the gate skip semantic processing as well as UI publication:

Current design:

accumulate text
gate
build assistant content
update reasoning metadata
yield to assistant-ui

That is why coalescing UI updates has spread into reasoning timing, split <think> tags, server summaries, terminal reconciliation, replay metadata, and every alternate publish path.

The simpler insertion point is:

accumulate text
build assistant content
update reasoning metadata
gate
yield to assistant-ui

This still coalesces the expensive downstream work that causes the visible backlog. Assistant-ui, React, markdown rendering, and browser painting receive fewer cumulative snapshots, while reasoning and replay bookkeeping continue to observe every arrival normally.

The available measurements suggest that retaining the content build on every chunk costs very little compared with the work after the yield. In the synthetic parser benchmark, 14,000 cumulative parses of a reply ending at 64,000 characters took about 55 to 65 ms total on this machine. By comparison, the actual browser backlog measured 11.4 to 11.8 seconds at 8x CPU throttling and 26.9 to 28.7 seconds at 12x. Coalescing publications reduced those backlogs to 1.38 to 1.44 seconds and 2.30 to 2.57 seconds respectively. A real Qwen3.5-0.8B-MTP run also dropped from 5.68 to 5.70 seconds of post-stream lag to 0.96 to 0.98 seconds at 12x throttling.

So we would give up a small extra parser CPU saving, but should retain nearly all of the user-visible improvement with a drastically smaller and easier-to-reason-about change. The final publish should remain unconditional, and state-bearing tool or replay events can still publish immediately. The held-text cap can also remain for Stop behavior.

I recommend moving the gate to immediately before the ordinary assistant-ui yield, removing the reasoning-specific gate timestamps and reconciliation paths, and rerunning the existing browser benchmarks to confirm that the practical improvement is unchanged.

Codex Review: Didn't find any major issues. You're on a roll.

Reviewed commit: e2ab2588cf

Agreed, and this is the right call. I raised something close to this at the point where the reasoning findings started repeating, then talked myself out of it after a few of the fixes landed cleanly. Your framing is better than mine was, because it identifies the actual mistake: the gate is skipping semantic processing as well as publication, and only the publication needed skipping.

I re-measured the parse cost independently before agreeing, since that is the load-bearing claim. Cumulative parseAssistantContent calls against a reply growing to 64,000 characters, warm, three runs:

plain text    parses=12800  final=64000c  total=371.4 / 33.9 / 35.0 ms
with <think>  parses=12793  final=64000c  total=307.1 / 33.6 / 40.8 ms

So about 34 to 41 ms warm, slightly cheaper than your 55 to 65, with the first run showing JIT warmup rather than real cost. Against 11.4 to 28.7 seconds of backlog that is not a tradeoff worth defending.

What the move deletes, on my count: gateHeldSince, gateReasoningEndedAt, the reconcileReasoning helper and its five call sites, the terminal flag that lifts the unclosed-tag guard, the split <think> tag search at the chunk join, the reconcile before the server summary frame, and the arrival-stamp lifecycle that four separate review rounds went into. Every one of those exists only because the tracker was learning about a group after it arrived. With the build ahead of the gate, it observes every arrival and none of that bookkeeping has anything to do.

Two things I would keep, and I think you are saying the same:

• state-bearing publishes stay ungated: tool_start / tool_end, a new delta.tool_calls entry, message-level replay metadata, and per-call extra_content. That last one is not in the current PR and matters on its own: Gemini puts the thought signature on the tool call, and a Stop that persists the call without it makes the next turn fail with a 400.
• MAX_HELD_CHARS, for exactly the Stop reason you give.

I have two fixes from the latest review round sitting unpushed and I am leaving them there rather than adding more reconciliation to code we have agreed to remove. One of them (the tool_args preview publishing without reconciling) disappears entirely under the new placement. The other is a pacing guard that survives it, and I will fold it in.

Happy to do the restructure and re-run the browser benchmarks at both throttling levels, or to leave it to you if you would rather drive it. Say which and I will get out of the way.

Done, in b9f4a73c2 and cfd307a0c. The gate now sits immediately before the assistant-ui yield.

What went

gateHeldSince, gateReasoningEndedAt, reconcileReasoning and its five call sites, adoptGatedReasoningGroups, the split-tag search at the chunk join, the reconcile before the server summary frame, and the back-dating arguments on startGroup / finishGroup. reasoning-duration.ts is byte-identical to its state before this PR. The adapter diff against the merge base drops from +311/-53 to +137/-22.

What stayed

One gate per run, the arrival counter and MAX_HELD_CHARS, and ungated publishes for anything state-bearing: tool_start / tool_end, a new delta.tool_calls entry, message-level replay metadata, and per-call extra_content. Also the skip for a chunk the ${...} strip left with nothing new, which is what the open review thread was about; it now covers tool-using turns too.

Does keeping the build on every chunk cost the improvement

This was the open question, so I measured it rather than reasoning about it. Same 64,000 character reply, 2000 chunks, in each engine, with a DOM write plus a forced layout read standing in for what is downstream of the yield. Median of three, after warming all three paths together:

=== chromium 151.0.7922.34 ===
  A publish every chunk (pre-PR)       2748 ms  publishes=2000  parses=2000  speedup=1.0x
  B gate before the build (original)     336 ms  publishes= 250  parses= 250  speedup=8.2x
  C gate after the build (this PR)       347 ms  publishes= 250  parses=2000  speedup=7.9x
  C keeps 99.5% of B's improvement

=== firefox 153.0 ===
  A publish every chunk (pre-PR)       3976 ms  publishes=2000  parses=2000  speedup=1.0x
  B gate before the build (original)     495 ms  publishes= 250  parses= 250  speedup=8.0x
  C gate after the build (this PR)       494 ms  publishes= 250  parses=2000  speedup=8.0x
  C keeps 100.0% of B's improvement

=== webkit 26.5 ===
  A publish every chunk (pre-PR)       9468 ms  publishes=2000  parses=2000  speedup=1.0x
  B gate before the build (original)    1238 ms  publishes= 250  parses= 250  speedup=7.6x
  C gate after the build (this PR)      1246 ms  publishes= 250  parses=2000  speedup=7.6x
  C keeps 99.9% of B's improvement

C does 8x the parses of B and lands within 11 ms of it on Chromium, inside noise on the other two. The stand-in cost is a lower bound on the real downstream work, so this understates C against A and overstates any gap between B and C. Your read was right.

Tests

Rewritten around the property the placement buys, rather than around the machinery it removes:

pacing must not be able to change a reasoning duration

Every case that cost a review round under the old placement (a split opening tag, the tag as its own delta, successive complete blocks, a later pass that opens bodyless, a long pause before the answer) is driven through the loop twice, publishing on every arrival and then on only the last, and required to agree. All five now do. Under the old placement each of them differed depending on which arrivals the gate let through.

41 tests became 26: the 17 reconciliation tests are gone with the code, and the ordering test now asserts the whole chain, that the rebuild and the tracker precede the gate and the gate precedes the yield. One test simply forbids the four removed names from coming back.

Mutation matrix rebuilt for the new shape: 24 mutations, all killed, including moving the gate back in front of the content build. It also caught a genuine gap while I was writing it, that inserting a gate in front of the tool_start / tool_end publish left the suite green; cfd307a0c pins that.

Suite 2415 passing, typecheck and build clean, 45/45 cross-engine scenarios in Chromium, Firefox and WebKit foreground and backgrounded, staging CI running now. Lint is unchanged: the same 10 pre-existing eslint errors in chat-adapter.ts before and after.

One thing worth doing that I have not: your throttled Studio numbers were measured against the old placement. The synthetic result says they should be unchanged, but if you still have that setup it would be worth one confirming run.

Codex Review: Didn't find any major issues. 🚀

Reviewed commit: 2ff1abd3b2

@codex review

Codex Review: Didn't find any major issues. 🚀

Reviewed commit: fb73e42fd2

End to end measurement, since everything up to now has been either synthetic or measured against the old gate placement.

Two isolated Studio installs, built by install.sh --local from the merge base 7fd3eeba75 and from head fb73e42fd. Three paired runs. Chromium at 8x CPU throttle applied identically to both sides and recorded per run. The reply is a fixed 60,000 character SSE body served by a local server, so both sides receive byte-identical input at the same rate; settled_chars came back 59,723 on all six runs, so the two halves painted exactly the same reply.

The visible effect is the freeze, not the total time

The stall ranges do not overlap across any of the three pairs. That number is the complaint in the PR description, that the page stops painting and Stop cannot run promptly: the un-paced build goes four seconds without updating the bubble at all, and the paced one never exceeds two thirds of a second.

Total time moves too, consistently, but only about 1.15x. I predicted a several-fold drop there and that prediction was wrong: once the publishes are coalesced, what remains is the cost of rendering a 60,000 character markdown message, which both builds pay in full. Worth stating plainly since it is the number a reader would expect to move most.

The stream duration difference is the backpressure effect, visible in Studio's own timing chip in the settled screenshots (4.38s against 2.85s): the saturated main thread slows the un-paced build's own reader.

What this does not show

A negative control at a stream slower than the renderer, where the two sides come out at 296s against 306s, i.e. identical within noise. The PR is a no-op when there is no backlog, which matches "slower streams still publish every chunk".

painted_pct_at_close is not usable and I would drop it from the PR body. Across these runs it read 10.7 to 100 on BEFORE against 78.6 to 100 on AFTER, and it systematically flatters BEFORE, whose socket closes late for the reason above. Reading that column naively would report this PR as a regression.

Four earlier attempts that produced clean-looking runs and proved nothing

Recording these because each one would have been publishable and wrong.

1. A real model produced roughly 2,000 characters. The rebuild this PR removes is quadratic in reply length, so at that scale there is nothing to measure, and free-form sampling gave the two sides different essays.
2. Generating the stream inside the page measures the wrong thing. The generator competes for the exact CPU budget the throttle is shrinking, so the stream slowed in lockstep with the renderer and neither side ever fell behind: 97% painted at socket close on both.
3. Studio serves connect-src 'self', so the helper server was blocked silently and delivered zero bytes with no error surfaced.
4. A 1.5 second stability window declares the reply finished in the middle of a freeze. One run had BEFORE "settle" at 3,461 characters against AFTER's 59,723, which is the backlog itself corrupting the measurement of the backlog.

Scene and the full record of what was observed are in pr_ui_scenes/chat_stream_fixed_bytes.py.
