openframe-oss-lib

openframe-oss-lib is the foundational backend library powering the OpenFrame platform — the AI-driven, open-source MSP infrastructure stack built by Flamingo.

This repository provides the shared Spring Boot libraries that every OpenFrame service is built upon: multi-tenant authentication, API layers (REST + GraphQL), reactive gateway routing, event streaming, real-time messaging, polyglot persistence, and distributed management workflows.

---

Features

• Multi-Tenant by Default — Every module implements strict tenant isolation: per-tenant RSA key pairs, tenant-scoped cache keys, tenant-scoped scheduler locks, and tenant ID embedded in every JWT
• Multi-Tenant OAuth2 Authorization Server — Per-tenant RSA key pairs, JWT issuance, PKCE support, dynamic client registration, SSO integration (Google, Microsoft), and invitation-based onboarding
• Relay-Compliant GraphQL + REST APIs — Netflix DGS GraphQL with DataLoaders for N+1 prevention alongside versioned REST controllers; cursor-based pagination throughout
• Reactive Edge Gateway — Spring Cloud Gateway + WebFlux + Netty; multi-issuer JWT validation, API key rate limiting, WebSocket proxying, and tool upstream resolution
• Event Ingestion & Streaming — Kafka / Debezium CDC processing pipeline with tool-specific deserialization, event enrichment, unified event type normalization, and Kafka Streams enrichment
• Real-Time Messaging — NATS JetStream publish/subscribe for device and tool notifications; persist-first notification strategy with read-state tracking
• Polyglot Persistence — MongoDB (sync + reactive), Redis (tenant-aware caching), Apache Pinot (analytics), Apache Cassandra (log storage)
• Distributed Schedulers — ShedLock + Redis for cluster-safe distributed job scheduling; offline device detection, API key stats sync, MDM fleet setup
• External REST API — API key–authenticated integration surface for third-party tools with OpenAPI documentation
• Tool SDKs — First-class Java clients for Tactical RMM, Fleet MDM, and MeshCentral
• Modular Maven Structure — 30+ independent modules; include only what your service needs
• Spring Boot 3.3 / Java 21 — Modern LTS Java with Spring Security OAuth2 and virtual thread readiness

---

Architecture

flowchart TD
    Client["Client / Browser / Agent"] --> Gateway["Gateway Service Core"]
    Gateway --> ExternalAPI["External API Service Core"]
    Gateway --> ApiCore["API Service Core (GraphQL + REST)"]

    ApiCore --> Authz["Authorization Service Core (OAuth2 / JWT)"]
    ApiCore --> Stream["Stream Service Core (Kafka / Debezium)"]
    ApiCore --> Management["Management Service Core (Schedulers)"]

    Authz --> Mongo["MongoDB"]
    ApiCore --> Mongo
    ApiCore --> Redis["Redis"]
    ApiCore --> Pinot["Apache Pinot"]
    Stream --> Kafka["Apache Kafka"]
    Stream --> Cassandra["Apache Cassandra"]
    Management --> NATS["NATS JetStream"]

Loading

---

Technology Stack

Layer	Technology
Language	Java 21
Framework	Spring Boot 3.3
Build Tool	Apache Maven 3.9+
Auth	Spring Authorization Server, Spring Security OAuth2
API	Netflix DGS (GraphQL), Spring MVC (REST)
Gateway	Spring Cloud Gateway + WebFlux + Netty
Persistence	MongoDB (sync + reactive), Redis, Cassandra, Apache Pinot
Messaging	Apache Kafka / Debezium CDC, NATS JetStream
Testing	JUnit 5, Testcontainers, RestAssured
Distributed Locking	ShedLock + Redis
Multi-tenancy	ThreadLocal tenant context, per-tenant RSA keys

---

Quick Start

Prerequisites

• Java 21 JDK (Eclipse Temurin 21 recommended)
• Apache Maven 3.9+
• Docker 24.x (for integration tests)
• GitHub Personal Access Token (PAT) with read:packages scope

1. Clone the Repository

git clone https://github.com/flamingo-stack/openframe-oss-lib.git
cd openframe-oss-lib

2. Configure GitHub Packages

Add your GitHub credentials to ~/.m2/settings.xml:

<settings>
  <servers>
    <server>
      <id>github</id>
      <username>YOUR_GITHUB_USERNAME</username>
      <password>YOUR_GITHUB_PAT</password>
    </server>
  </servers>
</settings>

3. Build the Library

mvn install -DskipTests

4. Add a Module as a Dependency

<dependencyManagement>
  <dependencies>
    <dependency>
      <groupId>com.openframe.oss</groupId>
      <artifactId>openframe-oss-lib</artifactId>
      <version>5.79.3</version>
      <type>pom</type>
      <scope>import</scope>
    </dependency>
  </dependencies>
</dependencyManagement>

<dependencies>
  <dependency>
    <groupId>com.openframe.oss</groupId>
    <artifactId>openframe-api-service-core</artifactId>
  </dependency>
</dependencies>

5. Run Tests

# Unit tests for a specific module
mvn test -pl openframe-core

# Integration tests (requires Docker)
mvn verify -pl openframe-data-mongo-sync

---

Module Overview

Module	Description
openframe-core	Core utilities, pagination, validation
openframe-exception	Standard exception hierarchy
openframe-core-crypto	Encryption utilities
openframe-security-core	JWT, PKCE, cookie service
openframe-security-oauth	OAuth2 BFF layer
openframe-authorization-service-core	Multi-tenant OAuth2 authorization server
openframe-api-lib	API contracts, filter DTOs, cursor pagination
openframe-api-service-core	REST + GraphQL API service layer
openframe-gateway-service-core	Reactive gateway, routing, security
openframe-data-mongo-common	MongoDB domain documents
openframe-data-mongo-sync	Synchronous MongoDB repositories
openframe-data-mongo-reactive	Reactive MongoDB repositories
openframe-data-redis	Redis tenant-aware cache
openframe-data-kafka	Kafka multi-tenant configuration
openframe-data-nats	NATS real-time messaging
openframe-data-cassandra	Cassandra log storage
openframe-data-pinot	Apache Pinot analytics queries
openframe-management-service-core	Distributed schedulers, startup initializers
openframe-stream-service-core	Kafka streams, Debezium event enrichment
openframe-external-api-service-core	External REST API for integrations
sdk/fleetmdm	Fleet MDM Java SDK
sdk/tacticalrmm	Tactical RMM Java SDK
clients/openframe-client	Rust cross-platform agent (openframe-agent-lib) — see clients/README.md

---

Documentation

📚 See the Documentation for comprehensive guides covering architecture, setup, development workflows, and reference documentation.

---

Community

All discussions, questions, and support happen on the OpenMSP Slack Community. We do not use GitHub Issues or GitHub Discussions.

• 🌐 OpenFrame Platform: https://openframe.ai
• 💬 OpenMSP Slack: https://www.openmsp.ai/
• 🦩 Flamingo: https://flamingo.run

---

Built with 💛 by the Flamingo team
